MD10 solid range
The MD10 with 0.18Nm breakaway torque is a miniature rotary feedthrough ideal for rotating small instrumentation loads in applications where space is limited.
Solid MagiDrive series
Our solid-shaft series of rotary feedthroughs.
UHV Design provides a range of standard shafts, all detailed in the product configuration options. However, customised shafts are also available if required. For longer shafts, where the concentricity and stability of the rotating shaft are critical, we offer a range of extended bearing housings. These are specifically designed to support the shaft along its axis of rotation. Details are available upon request.
Key Features
- Magnetically-coupled, fail-safe design Rotary Feedthrough
- Single-piece vacuum enclosure ensures leak-free performance
- Magnetic shielding permits use in magnetically-sensitive environments
- No bellows, organics or sliding seals
- Bakeable to 250ºC (including magnets)
- High torque-to-size ratio
- Zero backlash under low load and acceleration
- Hollow variants allow stacking of concentric drives
Solid MagiDrive series product options
MD16N/MD16A solid range
CF16, 1.33" OD flange, 0.45/1.8Nm torque
MD40N/MD40A solid range
CF40, 2.75" OD flange, 0.45/1.8Nm torque
MD40 solid range
The MD40 provides 9Nm break-away torque on a CF40 flange and is bakeable to 250°C without having to remove the outer magnets. Custom options also available.
MD64 solid range
The MD64 provides a high 10Nm breakaway torque on a CF64 flange. Bakeable to 250°C without having to remove the outer magnets. Custom options also available.
If you would like to discuss your project with our engineering team, please contact us.
